Hydraulic Excavator Swing Traveling Motor

Hydraulic Excavator Swing Traveling Motor is a key component that facilitates the rotational movement of the excavator superstructure. This motor is responsible for enabling the boom, arm, and bucket to pivot efficiently, allowing for precise maneuverability during excavation tasks. By utilizing hydraulic pressure, the motor converts fluid energy into mechanical movement, ensuring that the excavator can operate efficiently in a variety of terrains and conditions.

Send Inquiry

Product Description
Hydraulic Excavator Swing Traveling Motors are often equipped with various features to enhance their operational capabilities. These may include adjustable speed settings that allow operators to tailor the movement to specific tasks, as well as safety mechanisms that prevent over-rotation or mechanical failure. Therefore, this component not only helps to improve the efficiency of the excavator, but also plays an important role in ensuring the safety and effectiveness of excavation operations. It is designed to withstand huge loads and pressures while providing smooth and controlled rotation. The integration of advanced hydraulic technology ensures that operators can achieve optimal performance, thereby increasing productivity on the construction site. The design of the motor usually includes rugged materials and engineering to ensure durability and reliability during long periods of use.

Specification of Hydraulic Excavator Swing Traveling Motor

item value

Warranty 1 Year

Motor Type Piston Motor

Displacement 12cm³

Weight 85

Showroom Location Online Store

Pressure 210bar

Structure Hydraulic System


Selling Point

1.Rexroth Brand Hydraulic Motor: This hydraulic motor is made by the reputable Rexroth brand, providing assurance of high-quality and durable performance.

2.Piston Motor Function: This hydraulic motor operates as a piston motor, ensuring efficient and reliable operation within machinery.

3.Customizable Color: The hydraulic motor can be tailored to the user's specific color request, allowing for customization and integration into any machinery setup.

4.Fast Delivery Time: With a delivery time of 1-15 days, customers can receive their hydraulic motors quickly and efficiently.

5.Comprehensive After-Sales Service: This Rexroth hydraulic motor comes with a comprehensive after-warranty service, including online support for any issues that may arise.

6. 1 Year Warranty: Customers can rest assured with a 1-year warranty on this Rexroth hydraulic motor, providing protection and assurance of product quality.

7. 4 Bolt Square Flange Motor Flange Shape: The motor flange shape is designed for easy installation and compatibility with other machinery components.

8. Made in Germany: The hydraulic motor is proudly made in Germany, upholding the highest standards of quality and engineering expertise.

9. Suitable for Various Applications: This hydraulic motor is suitable for a variety of applications, including horizontal directional drilling, motor graders, and crawler cranes.

10. Energy Efficient: This hydraulic motor is designed for efficient power usage, reducing energy consumption and operating costs within machinery systems.

Input Flow 60 L/min 80 L/min 80 L/min
Motor Displacement 44/22 cc/r 53/34 cc/r 53/34 cc/r
Working Pressure 275 bar 275 bar 300 bar
2-Speed Switching Pressure 20~70 bar 20~70 bar 20~70 bar
Ratio Options 53.7 53.7 20.8
Max. Output Torque 10500 N.m 12500 N.m 5260 N.m
Max. Output Speed 50 rpm 44 rpm 113 rpm
Machine Application 6~8 Ton 6~8 Ton 6~8 Ton

Connection Dimensions

Frame Orientation Diameter A 210 mm 210 mm 210 mm
Frame Holes P.C.D B 244 mm 250 mm 244 mm
Frame Bolt Pattern M 12-M14 Equally 12-M16 Equally 12-M14 Equally
Sprocket Orientation Diameter C 250 mm 250 mm 250 mm
Sprocket Holes P.C.D D 282 mm 282 mm 282 mm
Sprocket Bolt Pattern N 12-M14 Equally 12-M14 Equally 12-M14 Equally
Flange Distance E 68 mm 68 mm 68 mm
Approximate Weight 75 kg 75 kg 75 kg



FAQ

1) What types of hydraulic motors does your company produce?

A: LANO mainly produces complete and fully assembled brand new axial piston motors integrated with planetary gearboxes, which are widely used for track equipment. We can also produce hydraulic motors for wheeled machines.


2) Hydraulic motors of which brands can be replaced with Lano's ones?

A: Our motors are interchangeable with the motors of the following brands: Eaton, Doosan, Jeil, KYB, Nachi, Nabtesco, Rexroth, Poclain, Bonfiglioli, etc.


3) How can I choose the right model of the hydraulic motor to fit my machine?

A: Different markets have different machine variations. The best way to find the right motor is to look at the motor brand and the machine model you have. Another way would be by measuring the key dimensions of the flange frame and the sprocket flange. Please contact our sales team to get technical support if you have difficulties choosing the right motor for your application.


4) Can you produce hydraulic motors based on your customer's designs and dimensions?

A: Yes, we can. We are ready to provide the best customized hydraulic solutions for your business.


5) Can the OEM parts apply to WEITAI's travel motors?

A: No, they cannot. Although they might have a similar appearance, their internal structures are different. Only lanoI's spare parts can fit WEITAI's travel motors.


6) What information do we need our customers to provide while choosing the right hydraulic motor for their application?

A: (1) Drawing, or (2) original motor model, or (3) machine model and part No.
